Pnematic Chute Model
| Technical Specifications | |
|---|---|
| Sealing Type | Center Seal, three side, four side |
| Filling Type | Vertical Type Auger filler |
| Roll Width | Min 80mm Max. 500mm |
| Main Motor | 24 30ratio 3000rpm |
| Heater Load | 1Kw |
| Electrical Supply | 1 Phase, 440 V / AC, 50 Hz |
| Packing Film | Any heat Sealable Laminate |
| Filling Range | 1 grm to 20 grms , 20 to 250 grms , 500 to 1000 grms |
| Compressed Air | 6CFM@6Bar |
| Temperature Controller | PID based |
| Machine Speed | 20-50 Pouch / Min. (depends upon the pouch size) |
| Contact Parts | Food Grade Stainless Steel SS 304 |
| Speed / machine Control | AC Drive / PLC based |
| Net Weight | 500 Kg. (Approx) |
| Optional Attachments | Hot foil Coding/inkjet coding, Nitrogen Flushing Device, take away elevator ( At an extra cost ) |
| Technical Specifications | |
|---|---|
| Sealing Type | Centre seal or 3 or 4 Side Sealing |
| Filling Type | Cup filler |
| Roll Width | Min 80mm Max. 500mm |
| Main Motor | 24 30ratio 3000rpm |
| Heater Load | 1Kw |
| Electrical Supply | 1 Phase, 440 V / AC, 50 Hz |
| Packing Film | Any heat Sealable Laminate |
| Filling Range | 1 grm to 20 grms , 20 to 250 grms , 500 to 1000 grms |
| Compressed Air | 6CFM@6Bar |
| Temperature Controller | PID based |
| Machine Speed | 20-50 Pouch / Min. (depends upon the pouch size) |
| Contact Parts | Food Grade Stainless Steel SS 304 |
| Speed / machine Control | AC Drive / PLC based |
| Net Weight | 500 Kg. (Approx) |
| Optional Attachments | Hot foil Coding/inkjet coding, Nitrogen Flushing Device, take away elevator ( At an extra cost ) |
| Technical Specifications | |
|---|---|
| Sealing Type | Centre seal or 3 or 4 Side Sealing |
| Filling Type | one head, two head, three head, four head |
| Roll Width | Min 80mm Max. 500mm |
| Main Motor | 24 30ratio 3000rpm |
| Heater Load | 1Kw |
| Electrical Supply | 1 Phase, 230 V / AC, 50 Hz |
| Packing Film | Any heat Sealable Laminate |
| Filling Range | 1 grm to 20 grms , 20 to 250 grms , 500 to 1000 grms |
| Compressed Air | 6CFM@6Bar |
| Temperature Controller | PID based |
| Machine Speed | For Single head 4-6Pouch / Min, for two head 10-12Pouch / Min, for three head 16-18Pouch / Min, for four head 22-24Pouch / Min (Depends upon nature of poducts) |
| Contact Parts | Food Grade Stainless Steel SS 304 |
| Speed / machine Control | AC Drive / PLC based |
| Net Weight | 500 Kg. (Approx) |
| Optional Attachments | Hot foil Coding/inkjet coding, Nitrogen Flushing Device, take away elevator ( At an extra cost ) |
| Technical Specifications | |
|---|---|
| Sealing Type | Centre seal or 3 or 4 Side Sealing |
| Filling Type | Horizontal Type Auger filler |
| Roll Width | Min 80mm Max. 500mm |
| Main Motor | 24 30ratio 3000rpm |
| Heater Load | 1Kw |
| Electrical Supply | 1 Phase, 240 V / AC, 50 Hz |
| Packing Film | Any heat Sealable Laminate |
| Filling Range | 1 grm to 20 grms , 20 to 250 grms , 500 to 1000 grms |
| Compressed Air | 6CFM@6Bar |
| Temperature Controller | PID based |
| Machine Speed | 20-50 Pouch / Min. (depends upon the pouch size) |
| Contact Parts | Food Grade Stainless Steel SS 304 |
| Speed / machine Control | AC Drive / PLC based |
| Net Weight | 500 Kg. (Approx) |
| Optional Attachments | Hot foil Coding/inkjet coding, Nitrogen Flushing Device, take away elevator ( At an extra cost ) |
| Technical Specifications | |
|---|---|
| Sealing Type | 3 or 4 Side Sealing |
| Filling Type | Paste Filling/liquid filling machine |
| Roll Width | Min 80mm Max. 500mm |
| Main Motor | ½ hp |
| Heater Load | 1Kw |
| Electrical Supply | Single Phase, 220 V / AC, 50 Hz |
| Packing Film | Any heat Sealable Laminate |
| Filling Range | 1 to 30 ml , 10 ml to 100ml , 30 to 300ml |
| Compressed Air | 6CFM@6Bar |
| Temperature Controller | PID based |
| Machine Speed | 20-50 Pouch / Min. (depends upon the pouch size) |
| Contact Parts | Food Grade Stainless Steel SS 304 |
| Speed / machine Control | AC Drive / PLC based |
| Net Weight | 500 Kg. (Approx) |
| Optional Attachments | Hot foil Coding/inkjet coding, Nitrogen Flushing Device, take away elevator ( At an extra cost ) |
